FURUTECH HF-A-NCF 1.5M ULTRA HIGH-SPEED HDMI Cable
330$
- Superior 48Gbps (GB/sec) bandwidth delivering ULTRA HIGH-SPEED HDMI™ CABLE 8K/60p
- 8K/60p/48Gbps , 4K/120p/32.08Gbps , HDCP1.4/2.2/2.3, eARC/ARC, HDR10/HDR10+
- Aluminum alloy connector with thick gold-plated contacts
- HDMI A connector parts treated with Furutech’s α(Alpha)-Process
- Double Layer Aluminum Foil Shields prevent Static and EMI.
- Exceeding stipulated specifications for Crosstalk and Noise double aluminum foil shielding for each twisted conductor.
- Featuring tension resistant Kevlar Synthetic Fiber to withstand external stresses.
- Antiresonance Sheath: passing UL/CL3 flame resistance testing and RoHS compliant, the very flexible PVC used in the HDMI-HF-A-NCF will reduce effects of electrical and mechanical resonance on signal transmission.
- The HDMI-HF-A-NCF cable has been purposely limited to a diameter of 4.7mm to produce an extremely light and flexible cable that delivers the highest possible performance.
Description
FURUTECH HF-A-NCF
Optical Fiber Copper UHD 8K 4K 48Gbps HDR10+ eARC 1.5m
Furutech’s HF-A-NCF HDMI cable is an active design (AOC) using a combination of fiber optics and high purity copper conductors to transmit the HDMI digital signal over long distances in a lossless and extremely stable manner, while drastically reducing the risk of EMI and RFI interference.
The HF-A-NCF offers a constant 48Gbps bandwidth and can handle 8K UHD or 4K HDR10+ streams, as well as all the latest HDMI technologies for an absolutely outstanding picture quality.
Noise resistant
The HF-A-NCF features the latest optical transmission technology, with its connectors incorporating special photoelectric conversion chips to provide optimal, balanced signal amplification. Even over distances that can cause noise sensitivity and signal degradation, the HF-A-NCF provides stable, lossless 8K signal transmission.
Optical fiber
The Furutech HF-A-NCF cable is equipped with an OM3 “multimode optical” fiber, which has a higher transmission speed and bandwidth than the OM1 and OM2. The bending diameter of the OM3 fiber is more than 20mm, which facilitates its use especially in environments that can make installation complex. This high quality cable is designed with great precision in an ISO 7 (Class 10000) cabinet room where the particle count is kept very low.
NCF
The cable clamp part of the HF-A-NCF incorporates Furutech’s patented electrical and mechanical damping material, the NCF (Nano Crystal² Formula). This crystalline material has two “active” properties. The first is the generation of negative ions to eliminate static electricity, the second is the conversion of thermal energy into far infrared. Furutech combines this material with nanometric ceramic particles and carbon powder for their additional damping properties by “piezoelectric effect”.
UHD 8K & HDR10+
By combining four multimode optical fibers and large copper conductors, the HF-A-NCF benefits from HDMI 2.1 certification, allowing for optimal transfer of 8K UHD streams at 60fps and 4K UHD streams at up to 120fps. High dynamic range technologies such as HDR, HDR10+ or Dolby Vision are also supported.
ARC & eARC
In addition to UHD support, the HF-A-NCF HDMI cable also provides seamless transmission of high-resolution audio streams and multi-channel tracks, including support for Dolby Atmos and DTS:X technologies. These streams can flow bi-directionally thanks to ARC and eARC technologies.
Technical characteristics
| SPECIFICATIONS | |
|---|---|
| Product type | Optical HDMI cable |
| Length | 1.5m |
| Connectors | 2x Male HDMI |
| Supported bandwidth | HDMI Ultra-High Speed 48Gbps |
| Supported resolutions | 8K/60p/48Gbps 4K/120p/32.08Gbps |
| Supported technologies | HDCP1.4/2.2/2.3 eARC / ARC HDR10 / HDR10+ VRR/60Hz~240Hz DSC QMS QFT ALLM |
| Connectors body material | Aluminum alloy + α (Alpha) treatment |
| Connectors contacts plating | Gold |
| Shielding | 2x Aluminum foils |
| External sheath | PVC |
| Cable diameter | 4.7mm (±0.2mm) |
